R22 SPECIFICATIONS
POWER PLANT
MODEL: Avco Lycoming O-320
TYPE: Four Cylinder, horizontally opposed direct drive, air cooled, normally aspirated, carburetor equipped.
NORMAL RATING: 160 BHP @ 2700 RPM
CONT. RATING: 124 BHP @ 2652 RPM
FUEL
TYPE: 100LL
CONSUMPTION: 7-9 U.S. gallons per hour
CAPACITY: Useable Main Tank:19.2 U.S. gallons
Useable Aux. Tank:10.5 U.S. gallons
FLIGHT LIMITS
MAX. OPERATING ALTITUDE: 14,000 feet
MAXIMUM. AIRSPEED: 117 mph
CRUISE AIRSPEED @ 75% PWR: 90 mph
WEIGHT LIMITS
EMPTY WEIGHT: 835 lbs
MAXIMUM GROSS WEIGHT: 1,370 lbs
MAXIMUM PER SEAT WEIGHT: 240 lbs
MINIMUM SOLO WEIGHT: 130 lb
